GGG-T-2761
6.
NOTES
(This section contains information of a general or explanatory nature that
may be helpful, but is not mandatory.)
6.1 Intended use. Material lifting tongs are lifting devices intended to be
used for lifting and moving pipe and conduit.
6.2 Ordering data. Purchasers should select the preferred options permitted
herein and include the following information in acquisition documents:
Title, number, and date of this specification.
b.
Class and size of tongs required (see 1.2).
c.
When the outside diameter of the pipe to be handled is to be
different, and when liners for these tongs are required (see 1.2
and 6.3).
d.
Issue of DODISS to be cited in the solicitation, and if required,
the specific issue of individual documents referenced (see 2.1.1
and 2.2).
e.
When first article is required for inspection and approval (see 3.2,
4.2.1, and 6.6).
f.
Color of finish coat, if different (see 3.6).
Level of preservation and packaging and level of packing required
g.
(see 5.1 and 5.2).
6.3 General information. When ordering tongs for handling material with
outside diameter other than mentioned in 1.2, the od must be specified in order
that the proper liners or spacer pads be furnished (see 6.2).
6.4 Samp ling procedures. Recommended inspection level is level II and
Acceptable Quality Level is 4.0 (see 4.3).
l
6.5 Data requirements. When this specification is used in an acquisition
and data are required to be delivered, the data requirements shall be developed
as specified by an approved Data Item Description (DD Form 1664) and delivered
in accordance with the approved Contract Data Requirements List (CDRL),
incorporated into the contract. When the provisions of DOD FAR Supplement,
Part 27, Sub-Part 27475.1 (DD Form 1423) are invoked and the DD Form 1423 is not
used, the data shall be delivered by the contractor in accordance with the
contract or purchase order requirements.
6.6 First art icle. When a first article inspection is required (see 3.2 and
6.2), the item will be tested and should be a sample selected from the first run
production items or it may be a standard production item from the contractor's
current inventory as specified in 4.2.1. The first article should consist of
one unit. The contracting officer should include specific instructions in
acquisition document regarding arrangements for examination, test, and approval
of the first article.
6.7 Supersession data.
This specification supersedes MIL-T-82009B(YD) dated
18 May 1984.
8
